Max. rated lifting capacity

kg

2000000

Max. hoist rope speed (Main winch)

m/min

125

Boom derricking up time

s

≥160

Boom extending time

min

≥20

slewing speed

r/min

≤0.8

Max. driving speed

km/h

75

Max. gradeability

%

33

Approach angle

°

16

Leave angle

°

22

Brake distance

m

10 (AT 30km/h)

Min. turning diameter

m

26

Min. ground clearance

mm

335

Deadweight in driving condition

kg

96000

Axles load

kg

12000

Overall dimensions (L×W×H)

mm

19990×3000×4000

Outrigger spread (L)

m

16

 Outrigger spread (W)

m

16

Main boom length

mm

19.2 ~ 103.1

Boom angle

°

-0.6 ~ 85

Luffing jib length

m

25+9

"Y"-guying system

yes
