Max. rated lifting capacity

kg

25000

Max. lift height of main boom

m

38.7

Max. lift height of jib
(The parameters do not include deflection of main boom and jib)

m

46.58

Max. hoist rope speed (Main winch)

m/min

135

Max. hoist rope speed (Auxiliary winch)

m/min

100

Boom derricking up time

s

120

slewing speed

r/min

2.6

Max. driving speed

km/h

72

Max. gradeability

%

34

Min. turning diameter

m

≤20

Min. ground clearance

mm

235

Fuel consumption per hundred kilometers

L

38

Deadweight in driving condition

kg

29400

Complete vehicle kerb mass

kg

29270

Front axle load

kg

6370

Rear axle load

kg

22900

Overall dimensions (L×W×H)

mm

12510×2500×3455

Outrigger spread (L)

m

5.15

 Outrigger spread (W)

m

6.1

Main boom length

mm

10.3 ~ 38.5

Boom angle

°

-2 ~ 80

Jib length

m

8

Offset

°

0,  30
