Max. rated lifting capacity

kg

30000

Max. lift height of main boom

m

40.5

Max. lift height of jib
(The parameters do not include deflection of main boom and jib)

m

48.5

Max. hoist rope speed (Main winch)

m/min

120

Max. hoist rope speed (Auxiliary winch)

m/min

100

Boom derricking up time

s

40

Boom derricking up time

s

80

Slewing speed

r/min

0 ~ 2.2

Max. driving speed

km/h

78

Max. gradeability

%

37

Min. turning diameter

m

≤22

Min. ground clearance

mm

220

Fuel consumption per hundred kilometers

L

35

Deadweight in driving condition

kg

32000

Complete vehicle kerb mass

kg

31870

Front axle load

kg

7000

Rear axle load

kg

25000

Overall dimensions (L×W×H)

mm

12900×2500×3465

Outrigger spread (L)

m

5.36

 Outrigger spread (W)

m

6.1

Main boom length

mm

10.6 ~ 40.0

Boom angle

°

-2 ~ 80

Jib length

m

8

Offset

°

0,  30
