Max. rated lifting capacity

kg

55000

Max. lift height of main boom

m

43.6

Max. lift height of jib
(The parameters do not include deflection of main boom and jib)

m

59.5

Max. hoist rope speed (Main winch)

m/min

120

Max. hoist rope speed (Auxiliary winch)

m/min

120

Boom derricking up time

s

50

Boom derricking up time

s

95

Slewing speed

r/min

0 ~ 2.2

Max. driving speed

km/h

76

Max. gradeability

%

40

Min. turning diameter

m

≤24

Min. ground clearance

mm

260

Fuel consumption per hundred kilometers

L

43

Deadweight in driving condition

kg

42000

Complete vehicle kerb mass

kg

41870

Front axle load

kg

16000

Rear axle load

kg

26000

Overall dimensions (L×W×H)

mm

13700×2800×3650

Outrigger spread (L)

m

5.92

 Outrigger spread (W)

m

7.1

Main boom length

mm

11.4 ~ 43.0

Boom angle

°

-2 ~ 80

Jib length

m

9.5, 16.0

Offset

°

0,  30
