Max. rated lifting capacity

kg

500000

Max. hoist rope speed (Main winch)

m/min

130

Boom derricking up time

s

≥90

Boom extending time

min

≥20

slewing speed

r/min

≤1.0

Max. driving speed

km/h

75

Max. gradeability

%

35

Approach angle

°

16.6

Leave angle

°

16

Brake distance

m

10 (AT 30km/h)

Min. turning diameter

m

29

Min. ground clearance

mm

335

Deadweight in driving condition

kg

96000

Axles load

kg

12000

Overall dimensions (L×W×H)

mm

21700×3000×4000

Outrigger spread (L)

m

11

 Outrigger spread (W)

m

11

Main boom length

mm

17 ~ 87

Boom angle

°

-0.5 ~ 84

 Fix Jib length

m

16 ~ 56

 Fix Jib offset

°

0,  15, 30

Luffing jib length

m

21 ~ 93

Goose-head jib length

m

5.6

"Y"-guying system

yes
